Linkage “Z” BAR
Engine Max Power 184 HP
Engine Emission TIER 4f – DEF
Breakout Force 26,455 lbs
Static Tipping Load, Full Turn 21,164 lbs
Bucket Capacity, Min/Max 3.5 – 3.9 cu/yd
Max Weight 31,195 lbs
Tyres 20,5 R25
Forks Load Capacity (EN 474-3) 12,346 lbs
Max Speed 25 mph

• Acoustic warnings
• Plugs with keys for fuel and hydraulic tanks
• Bucket with bolted teeth
• ROPS-FOPS-cab with heating and pressurizing systems, with front and rear windscreen wiper and windshield washer
• Tool box
• Spare parts catalogue
• Seat belt
• Limited slip differential on front axle
• Safety clamp for lifting cylinders
• Visual index for bucket position
• Working lights
• Draw bar hook
• Soundproofing
• Yellow rotating and overturning beacon
• Operation and maintenance manual
• Type-approval for road traffic
• Side rearview mirrors
• Complete instrument board
• Air conditioning

• Hydraulic or mechanical quick coupling
• Cement mixing bucket
• Multipurpose bucket (4in1)
• Speed reduction kit
• Lifting forks
• Proportional self locking differential on rear axle
• Asphalt and cement planer
• Snow blower
• V type snow blade
• Angle-tilt dozer blade
• Hand operated hammer
• Polishing brush
• Trencher wheel
